Southbend S36D-1G S-Series Range 4 Burners - 165,000 BTU
SKU
34000-083

Southbend S36D-1G S-Series Range 4 Burners
Stainless steel front, sides, and removable shelf. Individual, removable cast iron grate tops. Removable crumb drawers under burners. Metal knobs with red stripe. Hinged, lower valve panel. Quadrant spring door with heat resistant, ergonomic chrome handle. 6" stainless steel legs. Factory-installed pressure regulator. 12" Griddle, Std. Oven-35K BTU
Features:
- 36-1/2" wide open top with stainless steel front, sides, and removable shelf
- 28,000 BTU NAT (24,000 BTU LP) painted, one-piece cast iron, non-clog burners with a lifetime warranty
- 4-inch stainless steel front rail with closed, welded end caps
- Individual, removable cast iron grate tops (rear holds up to 14" stock pot)
- Removable, one-piece crumb drawer under burners
- Metal knobs with red stripe
- Hinged, lower valve panel
- Quadrant spring doors with ergonomic chrome handle
- 6-inch stainless steel, adjustable legs
- Factory-installed pressure regulator
*This item is built for restaurant applications. In case of residential or non-commercial use of any Commercial Equipment, the warranty shall not be honored.*
Southbend S36D-1G S-Series Range 4 Burners - 165,000 BTU
SKU
34000-083
Have Questions? Talk to our experts.
Product Highlights
- 36" S-Series Range, four 28,000 BTU burners, one 12" 18,000 BTU raised griddle (1/2" thick), one 35,000 BTU standard oven
- Stainless steel construction for shelf, sides, and front; 6" adjustable legs
- Porcelain-lined oven cabinet
- Standing pilot for oven ignition with convenient shut-off valve
Specifications
MFR # | S36D-1G |
---|---|
Brand | Southbend |
Height In Inches | 59.5 |
Width in Inches | 36.5 |
Depth In Inches | 34 |
BTU per Hour | 165,000 |
Top Configuration | 4 open burners & 12" griddle |
Burner Style | Grates |
Number of Burners | 4 |
Number of Ovens | 1 |
Gas Inlet Size | 3/4" |
Base Style | Standard Oven |
Warranty | 1-Year Limited Parts and Labor Warranty |
Product Type | Commercial Gas Range |
