Hobart AM16VL-ADV-2 High-Temp Door-Type Automatic Soil Removal Ventless Dishwasher Up to 40 Racks per Hour 208-240/60/3 (Field Convertible to 1Ph)
SKU
27000-100
New
Free Shipping
Hobart AM16VL-ADV-2 High-Temp Door-Type Automatic Soil Removal Ventless Dishwasher Up to 40 Racks per Hour 208-240/60/3 (Field Convertible to 1Ph)
SKU
27000-100
USD $28,229.31
Have Questions? Talk to our experts.
Product Highlights
Hobart AM16VL-ADV-2 High-Temp Door-Type Automatic Soil Removal Ventless Dishwasher Up to 40 Racks per Hour 208-240/60/3 (Field Convertible to 1Ph) USA
- .67 gallons per rack pumped final rinse
- 40 racks per hour – hot water sanitizing
- Drain water energy recovery (DWER)
- Automatic soil removal (ASR)
- Ventless energy recovery
- Pillarless opening
- 5-sided insulated hood
- User-friendly smart touchscreen controls
- Single point electrical connection standard, field convertible to dual point connection
- 3 phase standard, field convertible to single phase
- WiFi connectivity
- SmartConnect app and cloud with machine status, temperature logs, error code reporting, and cost, consumption and usage analysis
- Temperature and chemical lock outs (with Hobart equipped chemical pumps)
- Pumped drain
- Door lock
- Timed wash cycles for 1, 2, 4 or 6 minutes
- NSF pot and pan rating for 2-, 4- & 6- minute cycles
- Sense-A-Temp™ 70°F rise electric booster heater
- Self-draining, high efficiency wash pump with stainless steel impeller
- 17" door opening
- Stainless steel drawn tank, tank shelf, chamber, trim panels, frame and feet
- Spring counterbalanced chamber with reinforced, thermo-plastic rollers
- X- shaped revolving, interchangeable upper and lower anticlogging wash arms
- Revolving, interchangeable upper and lower rinse arms
- Slanted, self-locating, one-piece scrap screen and basket system
- Automatic fill
- Door actuated start
- AutoClean
- Factory installed drain water tempering kit
- Factory startup
- Service diagnostics
- Straight-through or corner installation
- Auto delime
Product Files
Product Overview
The Hobart AM16VL-ADV delivers powerful, high-temperature sanitizing performance without the need for external ventilation. Its ventless energy-recovery system captures heat and steam from the drain water to preheat the rinse cycle, reducing energy use and improving efficiency. The Automatic Soil Removal (ASR) feature filters food debris during operation, minimizing pre-scrapping and extending wash-water life. Using only 0.67 gallons of water per rack, it offers exceptional efficiency for high-volume kitchens. Built with a durable stainless steel tank and intuitive touchscreen controls with WiFi connectivity, the AM16VL-ADV simplifies monitoring, maintenance, and daily operation.
Options & Accessories (Available at extra cost)
- Peg, combination and wine rack
- ASR left hand conversion kit
- Chemical pumps
- Splash shield for corner installations
- Flanged and seismic feet
- Water hammer arrestor kit
- Door lock kit
- Rapid fill kit
- Prison package
- Marine package
Notes
- All dimensions taken from floor line may increase 7/8" or decrease 3/8" depending on leg adjustment.
- Net weight of machine including booster: 360 lbs.
- Domestic shipping weight including booster: 380 lbs
- Size of racks – 19-3⁄4" x 19-3⁄4".
- Backflow prevention provided by NSF-approved air gap device.
- For optimal performance, Hobart recommends maintaining a dishroom temperature of 65°F (18°C) or higher, as lower temperatures may hinder the machine’s capacity to operate effectively (with lower performance as ambient temperature decreases).
Plumbing Notes
- Water hammer arrestor (meeting ASSE-1010 standard or equivalent) to be supplied (by others) in common water supply line at service connection.
- Recommended water hardness to be 3 grains or less for best results.
- This is a pumped rinse machine. Pressure regulating valve is not necessary on hot or cold lines.
UPC: 62828801270001003
Specifications
Hobart AM16VL-ADV-2 High-Temp Door-Type Automatic Soil Removal Ventless Dishwasher Up to 40 Racks per Hour 208-240/60/3 (Field Convertible to 1Ph) USA
| Manufacturing origin | United States |
|---|---|
| MFR # | AM16VL-ADV-2 |
| Brand | Hobart |
| Net Weight | appx 360 lbs |
| Total Depth | 37.4" |
| Total Width | 30" |
| Total Height | 59" (78 1/2" at max open door height) |
| Capacity | 10.5 U.S. Gallons Wash Tank Capacity |
| NEMA | Barewire - Needs a certified eletrician to wire on field, field convertible to Single phase |
| Amps | 53.5 A (Electric Heat Requires 26.9 A, and Booster & Controls requres 26.6 A when field converted to Dual Point 3 Phase) |
| Horsepower | 0.18 HP (Rinse Pump) ; 2 HP (Wash Pump); 0.21 (ASR Pump); 0.21 HP (Drain Pump); 0.05 HP (Blower) |
| Hertz | 60 |
| Voltage | 208-240V |
| Phase | 3 (Field convertible to 1) |
| Door Style | Solid Door |
| Door Type | Vertical lift hood |
| Drain Size | 1-1/2" stainless steel tube fitting 19" AFF |
| Flow Rate | Peak Rate of Drain flow 18.5 U.S. Gallons per Minute (initial rate with full tank) |
| Water Inlet Size | 3/4" female garden hose fitting on 6' long hose supplied with machine |
| Booster Heater Included | Yes - Electric Booster 7.1 kW; Electric Heating Unit 5.4 kW |
| Number of Wash Cycles | 4 Cycles |
| Wash Cycle Time | Adjustable based on preference - Timed wash cycles for 1, 2, 4 or 6 minutes |
| Racks Per Hour | Up to 40 Racks / hr or 1000 Dishes (average 25 per rack) / hr or 1800 Glasses (average 45 per rack) / hr |
| Water Usage | 0.67 Gallons Per Rack (Rinse); 26.8 Gallons per Hour (Max. Consumption) |
| Warranty | One year parts and labor warranty provided by Hobart |
| Product Type | Door-type dishwasher, High Temp, Ventless, Tall Chamber, ASR |
| Style | High-Temp Sanitizing |
| Electrical | 208-240V / 60 / 3 (Field Convertible to 1Ph) |
