MODEL 11- 10 INCH MEAT SAW

The Biro Model 11 Power Cutter with 10” Dia. (254mm) saw blade wheels, is equipped with a 1-1/2HP (1.1kw) motor and toggle switch as standard. A powder coated steel base structure, with aluminum head and door structure is also standard. The removable platter and meat carriage are stainless steel.

Designed for use in small meat shops, grocery stores, deli’s, and restaurants, this saw is excellent for boneless meats, chicken, and pork cutting.

This saw exhibits proven design concepts along with the durability and reliability found in other Biro Power Cutters. The single flange saw blade wheel design protects the blade’s tooth set and teeth tips. The Model 11 disassembles without tools for easy cleaning and is economical to use.

SPECIFICATIONS

MODEL

11 POWER CUTTER

CONSTRUCTION

STEEL PLATE POWDER COATED BASE, ALUMINUM HEAD.

MOTORS

HP	KW	TYPE	VOLTS	AMPS	CYCLE	PH	STATUS
1 1/2	1.1	TE	115/208-230	17.4/7.0-8.7	60	1	STD
1 1/2	1.1	TE	208-230/460	4.4-4.0/2.0	60	3	STD
1 1/2	1.1	TE	380	2.4	50	3	STD
1 1/2	1.1	HH	220	6.8	50	1	EC

TE=TOTALLY ENCLOSED STD=STANDARD HH=HIGH HUMIDITY EC=EXTRA COST

STANDARD FEATURES

ONE SAW BLADE, SAFETY PUSHER PLATE, SAFETY WALL POSTER, OPERATION AND SAFETY MANUAL.

SWITCH

TOGGLE, STANDARD, 2 HP RATED, PLACED CONVENIENTLY IN FRONT.

HEAD AND DOOR

ALUMINUM, ENTIRE ASSEMBLY REMOVABLE.

BASE STRUCTURE

WELDED STEEL PLATE, POWDER COATED FINISH.

BLADE STANDARD

HARD TOOTH .020 INCH (.4 MM) THICK, FOUR TEETH PER INCH, 5/8 INCH (15.9 MM) WIDE, 78” (1981 MM) LONG, ONE SUPPLIED WITH EACH SAW.

BLADE SPEED

3000 FEET (914 M) PER MINUTE APPROXIMATE, FOR BOTH 50 AND 60 CYCLE OPERATION.

BLADE GUIDE

UPPER AND LOWER BLADE BACK-UP LONG LIFE CARBIDE INSERT GUIDE ASSEMBLIES, REMOVABLE.

BLADE TENSION

RATCHET ARM AND CAM AGAINST POUND TESTED SPRING AND TENSION SPRING GAUGE.

BLADE WHEELS

10” (25.4 CM) CAST IRON, CHROME NICKEL PLATING, UPPER WHEEL ASSEMBLY LIFTS OUT.

BEARINGS

HEAVY DUTY TAPERED ROLLER BEARINGS IN UPPER WHEEL HUB AND LOWER BEARING HOUSINGS.

CATCH PAN

POLY, EXTRA DEEP, ROUNDED CORNERS, SEALED OFF FROM OTHER PARTS OF BASE, ACCESSIBLE THROUGH BASE HINGED DOOR.

CLEANING UNIT

LONG LIFE CARBIDE GUIDE, STEEL SAW CLEANERS, REMOVABLE AS A UNIT FOR EASY CLEANING, (ASSEMBLY ALSO ADJUSTABLE AS A UNIT).

DRIVE SYSTEM

NON-SLIP SILENT V-BELT, TENSION ADJUSTABLE.

LEGS

STRAIGHT (WITH FLOOR PADS), NON ADJUSTABLE.

MEAT CARRIAGE

STAINLESS STEEL WITH NYLON GUIDES AND STEEL BEARINGS.

MEAT GAUGE PLATE

STAINLESS STEEL FACED, ADJUSTABLE FROM 1/16” (1.59 MM) TO 6-1/2” (165 MM), LOCKS IN POSITION, CAN BE TAKEN OUT OF GEAR, ENTIRE ASSEMBLY REMOVABLE FOR CLEANING.

MOTOR COMPARTMENT

SEALED OFF FROM MEAT CONTACT AREAS, EASILY ACCESSIBLE THROUGH REMOVABLE PANEL DOOR.

PLATTER

ALL STAINLESS STEEL, HELD IN PLACE WITH TWO PUSH PULL HOLD DOWN STAINLESS STEEL RODS.

SAFETY PUSHER PLATE

STANDARD, STORAGE CLIP PROVIDED.

OPTIONS (EC)

POWER CORD AND PLUG, TOTALLY ENCLOSED MOTOR, WATERTIGHT MAGNETIC SWITCH WITH THERMAL OVERLOAD AND UNDER VOLTAGE PROTECTION, NSF CERTIFICATION.

CERTIFICATION

C.S.A. on 115-60-1, U.L., N.S.F.



WEIGHT

UNCRATED: 256 LBS. (116 KG) APPROXIMATE. CRATED: 308 LBS. (140 KG) APPROXIMATE.

DIMENSIONS CRATED

L = 32” (81.3 CM), W = 40” (101.6 CM), H = 41” (104 CM).
