Vulcan LG400 45-50 lb Gas Floor Fryer - 120,000 BTU - Propane
- 45-50 lb oil capacity
- Stainless steel constructed fry tank
- 200° - 400°F (93°-204°C) temperature range
- Millivolt system requires no electric hook-up
- Twin fry baskets with plastic coated handles
- High-limit shut-off protector shuts off gas combination valve and standing pilot
- 120,000 BTU; Propane
Talk to our experts- 1-855-926-3826
- Email
Vulcan LG400 45-50 lb Gas Floor Fryer - 120,000 BTU - Propane
The LG400 commercial fryer requires fewer BTUs resulting in lower operating costs for your restaurant.
This freestanding model fryer is available in 45-50 lb oil capacity with 120,000 BTU. It includes twin fry baskets with plastic coated handles and drain extension. This propane gas fryer has a large "V" shaped cold zone and 1 1/4" port ball valve that helps preserve oil used in the fryer by catching leftover food particles and cooling them, which prevents them from burning and tainting the oil. A door snap action millivolt thermostat control allows the temperature to be adjusted from 200° to 400°F. This helps in avoiding the requirement of an electric hook-up.
The LG400 is constructed with a stainless steel front top and reinforced door. The stainless steel fry tank has a five five-year limited tank warranty. To ensure the door is closed properly an earth magnet has been used. A door liner has also been added for added stability.
STANDARD FEATURES
- Stainless steel fry tank with 45-50 lb capacity
- Large cold zone area.
- 11⁄4" full port ball type drain valve.
- Stainless steel reinforced door.
- G90 high-grade galvanized non-corrosive finish sides and back.
- Door liner for added stability.
- Set of four nickel-plated adjustable legs.
- Twin fry baskets with plastic coated handles.
- 120,000 BTU’s/hr. input.
- Behind the door snap, action millivolt thermostat control adjusts from 200° to 400°F with standing pilot.
- Millivolt System - Requires no electric hook-up.
- Hi-limit shut-off protector shuts off gas combination valve and standing pilot.
- Built-in flue deflector.
- Nickel-plated tube rack.
- Earth magnet to secure closed door.
- Easily removable stainless steel basket hanger for cleaning.
- Vulcan-Hart (Vulcan) warrants the LG Series gas fryer to be free of defects in materials and workmanship for a period of 1 year from the date of original installation.
- The stainless steel fry tank has a five (5) year limited tank warranty. If during the first year only, the tank is found to have a leak and is verified by an authorized service agency, the entire LG Series fryer will be replaced.
Specification
| More Options | Fuel Type |
|---|---|
| MFR # | LG400 |
| Brands | Vulcan |
| Height In Inches | 34.625 |
| Width in Inches | 15.5 |
| Depth In Inches | 29.75 |
| BTU per Hour | 120,000 |
| Temperature Range | 200 to 400 degree F |
| Number of Fryer Baskets | 2 |
| Gas Inlet Size | 1/2" and 3/4" |
| Control Type | Thermostatic |
| Capacity | 45 to 50 lbs of oil |
| Product Type | Gas Floor Fryer |
