S684-36G Electric Range with 36" Griddle
S684-36G Electric Range with 36" Griddle
Product Highlights
S684-36G Electric Range with 36" Griddle Canada
  - Stainless steel exterior
 - 2 large, full-size ovens with complete porcelain interior finish
 - Removable, 4 positions, oven rack guides with one oven rack per oven
 - Electro-mechanical heavy-duty oven thermostat, (150°F/66°C - 550°F/288°C)

Product Files
Product Overview
S684-36G
Standard Features:
- Stainless steel exterior
 - 2 large, full-size ovens with complete porcelain interior finish
 - Removable, 4 positions, oven rack guides with one oven rack per oven
 - Electro-mechanical heavy-duty oven thermostat, (150°F/66°C - 550°F/288°C)
 - "S" series models have 10 tubular heating elements, infinite switch controlled
 - Cool touch oven door handle
 - 10" (254mm) high stainless steel backguard with slotted black enameled angled cap
 - 6" (152mm) high stainless steel adjustable legs

Optional & Accessories:
- Convection oven(s), (add suffix - RC for sgl., or -RC2 for dbl.) Each convection oven comes standard with 3 oven racks
 - 5/8" (16mm) thick thermostatically controlled griddle plate available in 12", add suffix 12G, 24" add suffix 24G and 36", add suffix 36G, standard on the right-left optional
 - Solid Steel Hot top 1/2" (13mm) thick utilizing font and rear switch controls, available in 12", add suffix 1, 24" add suffix 2, and 36", add suffix 3, standard on the left, right optional (Note: Maximum (3)three hot top sections per range.)
 - Additional Oven Rack
 - Set of (4) Polyurethane(non-marking) swivel casters with front brakes.
 - 17" (432 mm) high stainless steel backgaurd with slotted black enameled angled cap
 - Stainless steel two-piece easy to assemble backguard and plate shelf
 - Range mounted salamander broiler (Model SER-680). CE Marked range mounted salamander is SUER-680. Specify right or left side, 24"wide high-shelf included.
 - Marine equipment - storm rails for pots, oven door latch, drip tray stop, and deck fasteners

Electric medium-duty range with 2 full-size ovens, the all-porcelain oven interior, contoured front stainless steel plate rail, 60" (1524mm) wide, with 10 all-purpose tubular heating elements. Stainless steel exterior, with stainless steel 10" (254mm) high backyard with slotted black enameled angled cap. Available with optional sealed elements with "overheat protection" – reducing power if the element is turned on w/o pan for 8 minutes, hot top(s), and griddle. Available with convection oven base(s).
NOTE: Ranges supplied with casters must be installed with an approved restraining device.
Specifications
S684-36G Electric Range with 36" Griddle Canada
| MFR # | S684-36G |
|---|---|
| Wattage | 27 Kilowatts |
| Product Type | All purpose tubular element burners |
| Number of Burners | 10 |
| Exterior Material | Stainless Steel |
| Temperature Range | 66°C - 288°C | 150°F - 550°F |
| Voltage | 208V |
| Total Depth | 34-1/4 |
| Total Width | 60 |
| Total Height | 47 |
| Warranty | 1 YEAR WARRANTY PARTS AND LABOR |
