• Stainless steel top, front and sides
• 28" (711 mm) wide baking chamber
• 18" (457 mm) wide, 56" (1422 mm) long conveyor belt with product stop
• Front removable fingers and conveyor belt
• Double stackable in ventless operation (Max. double stack)
• Front loadng glass access door with cool touch handle
• 3" (76.2 mm) conveyor openning
• Includes oven start-up / check-out by Welbilt authorized service agent (U.S. Continental)

Controls Specification

• Adjustable temperature from 250ºF (121ºC) to 600ºF (316ºC) to accomodate a wide range of products
• Adjustable conveyor speed from 20 seconds to 30 minutes
• Front mounted easyTouch controls include 8 preset menu items, reversible belt direction, adjustable temperature and cooktime

Fastbake Configuration (Must be specified at the time of purchase)

• KF005 - FastBake Kit - Right to Left
• KF006 - FastBake Kit - Left to Right

Cooking Specification

• Venless models available with Fastbake only
• FastBake technology reduces cook time by up to an additional 3% with no food qualify loss or noise increase

Optional Accessory

• KNLZ Certified models available for Ventless operation (UL KNLZ is a category that restrict emit to be less than 5.0 mg/m3 of particulate matter emission)
• SIngle and three phase cord sets
• 12" entry and exit shelves
• Counter mount stand (single stack only)
• Stand with casters (single and double stack)

*Each oven deck requires voltage, phase and hertz as indicated by model number. Neutral must be grounded at electrical service and receptacle properly polarized. Gas 120V units have a cord with NEMA 5-15 plug. All other models have terminal  lock connections. It is recommended that a separate circuit breaker be provided for each oven deck.

Recommended Minimum Clearances

• Rear of oven to Combustible Surface: 6” (152mm). Additional clearance on right hand side from other cooking equipment: 24” (610mm). The conveyor is removable from the front.
