Jet-Tech 747HH High Temp Door-Type Pan/Warewasher - 30 Racks/hr

SKU
41000-174
CAD $16,978.00

Call 18559263826 for pricing!

Free Shipping
Certifications
icon-0 icon-1 icon-2 icon-3

Whether you operate a bakery, hotel, supermarket, school, meat department, hospital, or laboratory, these highly productive dishwashers will ensure perfect kitchen ware hygiene; specially designed to effectively ensure total coverage and contribute to an impeccable cleanliness. Ensure washing of every kind of wares with these dishwashers. That is how the Total Clean Concept will make your life a whole lot easier!



PRODUCT DESCRIPTION:

  • Built-in booster for superior sanitation
  • Fully automatic program with wash phase at 150F and final rinse phase at 185F
  • Capacity: 40 racks per hour
  • Wash dishes or trays with a maximum height of 26"
  • 24" x 24" foot print cabinet
  • Stainless steel wash and rinse arms
  • Built-in rinse-additive and detergent pump for sparkling results



PERFOMANCE FEATURES:

  • High hood opening facilitates the washing of tall items
  • Completely automatic wash and rinse programs with a wash cycle of 150° (65°C) with detergent and rinse cycle of 185°F (85°C)
  • Model 747HH is built with twin wash motor pumps of 1 HP each (total of 2 HP) for greater power and enhanced performance
  • Insulated lower cabinet provides for a quieter operation
  • Adjustable detergent and rinse-additive pumps are provided is standard equipment
  • Large capacity opening permits the washing of sheet pans and mixing bowls of up to 26” high x 20” wide
  • Door-activated automatic start and stop mechanism for ease and convenience
  • Designed to be installed either in a corner or straight pass through set up



CONSTRUCTION FEATURES:

  • Body, external housing, wash tank, adjustable bullet feet and all chassis components are of 16 Ga. in 304 painted stainless steel
  • Individual wash pumps for upper and lower washing assemblies
  • Fully enclosed insulated lower cabinet provides a quieter operation
  • Three way sliding counter balanced doors assembled with heavy duty stainless steel bushing and door handle for ease of operation and durability
  • Safety micro-switch on the door to interrupt wash pump action
  • Independently operated heating elements alternating between booster and wash tank
  • Alternating heating resistors reducing maximum absorption thereby reducing energy costs
  • Wash tank fabricated with an integrated set of perforated stainless steel scrap fillers which are easily removed for quick cleaning and proper maintenance
  • Two individual scrap fillers protect the twin wash-motor pumps
  • Lower front and side panels are easily removed for technical access
  • Individual digital gauges for both wash and rinse temperatures
  • Automatic fill and water level regulation of the wash tank
  • Standard equipment includes: One 20” x 20” stainless steel 10-place sheet pan rack and one 20” x 20” peg rack for dishes

Specification

More Information
MFR # 747HH
Brands JET-TECH
Depth In Inches 20.375
Width in Inches 42.5
Height In Inches 98.5
Capacity 19.75" x 19.75" (rack)
Amps 50 (single phase) or 29 (three phase)
Horsepower 2 x 1.0 HP
Hertz 60
Voltage 208-240V
Phase 1 or 3
Door Style Solid Door
Drain Size 1.5"
Flow Rate 49.75 US gal/hr
Water Inlet Size 3/4"
Booster Heater Included Yes
Wash Cycle Time 105 seconds
Water Usage 1.0 US gal/cycle
Warranty 1-Year Parts & Labour
Product Type Dishwashing Equipment

Resources and Download

SPECSHEET ( 507.18 kB)
EXPLODED VIEW ( 1.02 MB)
ELECTRICAL ( 200.12 kB)
