Hobart AM16T-ASR-2 High-Temp Door-Type Tall Chamber (27") Automatic Soil Removal Dishwasher Up to 52 Racks per Hour 208-240V/60/3 (Field Convertible to 1Ph)
SKU
27000-099
New
Free Shipping
Hobart AM16T-ASR-2 High-Temp Door-Type Tall Chamber (27") Automatic Soil Removal Dishwasher Up to 52 Racks per Hour 208-240V/60/3 (Field Convertible to 1Ph)
SKU
27000-099
CAD $40,542.39
As low as CAD $1,455.47/mo. with EconoLease. Learn more
Have Questions? Talk to our experts.
Product Highlights
Hobart AM16T-ASR-2 High-Temp Door-Type Tall Chamber (27") Automatic Soil Removal Dishwasher Up to 52 Racks per Hour 208-240V/60/3 (Field Convertible to 1Ph) Canada
- .67 gallons per rack pumped final rinse
- 52 racks per hour – hot water sanitizing
- Automatic soil removal (ASR)
- Pillarless opening
- 3-sided hood
- User-friendly smart touchscreen controls
- Single point electrical connection standard, field convertible to dual point connection
- 3 phase standard, field convertible to single phase
- WiFi connectivity
- SmartConnect app and cloud with machine status, temperature logs, error code reporting, and cost, consumption and usage analysis
- Temperature and chemical lock outs (with Hobart equipped chemical pumps)
- Pumped drain
- Timed wash cycles for 1, 2, 4 or 6 minutes
- NSF pot and pan listed for 2-, 4- & 6- minute cycles
- Sense-A-Temp™ 70°F rise electric booster heater
- Self-draining, high efficiency wash pump with stainless steel impeller
- 27" door opening for 18" x 26" sheet pans or 60-quart mixing bowl
- Stainless steel drawn tank, tank shelf, chamber, trim panels, frame and feet
- Spring counterbalanced chamber with UHMW guides
- X- shaped revolving, interchangeable upper and lower anticlogging wash arms
- Revolving, interchangeable upper and lower rinse arms
- Slanted, self-locating, one-piece scrap screen and basket system
- Automatic fill
- Door actuated start
- AutoClean
- Drain water tempering kit
- Factory startup
- Vent fan control
- Service diagnostics
- Straight-through or corner installation
- Auto delime
- Sheet pan rack
Product Files
Product Overview
The Hobart AM16 ASR Tall Door-Type Dishwasher combines exceptional cleaning power with a spacious, high-clearance chamber, engineered to handle everything from standard dishware to full-size sheet pans and large kitchen utensils. Built for versatility, reliability, and efficiency, it’s the perfect choice for busy kitchens that need to wash more in less time without sacrificing cleanliness or performance.
With its increased door opening and deep wash cavity, the AM16 ASR easily accommodates full 18" × 26" sheet pans, mixing bowls, and larger kitchen items that don’t fit in standard dish machines. This added clearance eliminates the need for manual scrubbing of oversized wares, streamlining operations and saving valuable labor. It’s an ideal solution for bakeries, catering operations, and high-volume restaurants that demand complete wash coverage for large cookware and trays.
Options & Accessories (Available at extra cost)
- Peg, combination and wine rack
- ASR left hand conversion kit
- Chemical pumps
- Splash shield for corner installations
- Flanged and seismic feet
- Water hammer arrestor kit
- Door lock kit
- Rapid fill kit
- Prison package
- Marine package
Notes
- All dimensions taken from floor line may increase 7/8" or decrease 3/8" depending on leg adjustment.
- Net weight of machine including booster: 325 lbs.
- Domestic shipping weight including booster: 345 lbs.
- Size of racks – 19-3⁄4" x 19-3⁄4".
- Backflow prevention provided by NSF-approved air gap device.
- For optimal performance, Hobart recommends maintaining a dishroom temperature of 65°F (18°C) or higher, as lower temperatures may hinder the machine’s capacity to operate effectively (with lower performance as ambient temperature decreases).
Plumbing Notes
- Water hammer arrestor (meeting ASSE-1010 standard or equivalent) to be supplied (by others) in common water supply line at service connection.
- Recommended water hardness to be 3 grains or less for best results.
- This is a pumped rinse machine. Pressure regulating valve is not necessary on hot or cold lines.
UPC: 62828801270000990
Specifications
Hobart AM16T-ASR-2 High-Temp Door-Type Tall Chamber (27") Automatic Soil Removal Dishwasher Up to 52 Racks per Hour 208-240V/60/3 (Field Convertible to 1Ph) Canada
| Manufacturing origin | United States |
|---|---|
| MFR # | AM16T-ASR-2 |
| Brand | Hobart |
| Net Weight | appx 360 lbs |
| Total Depth | 32 1/4" |
| Total Width | 29 13/16" |
| Total Height | 67 5/8" (90 5/8" at max open door height) |
| Capacity | 10.5 U.S. Gallons Wash Tank Capacity |
| NEMA | Barewire - Needs a certified eletrician to wire on field |
| Amps | 53.5 A (Electric Heat Requires 26.9 A, and Booster & Controls requres 26.6 A when field converted to Dual Point 3 Phase) |
| Horsepower | 0.18 HP (Rinse Pump) ; 2 HP (Wash Pump); 0.21 HP (Drain Pump); 0.18 HP (ASR Pump) |
| Hertz | 60 |
| Voltage | 208-240V |
| Phase | 3 (Field convertible to 1) |
| Door Style | Solid Door |
| Door Type | Vertical lift hood |
| Drain Size | 1-1/2" stainless steel tube fitting 19" AFF |
| Flow Rate | Peak Rate of Drain flow 18.5 U.S. Gallons per Minute (initial rate with full tank) |
| Water Inlet Size | 3/4" female garden hose fitting on 6' long hose supplied with machine |
| Booster Heater Included | Yes - Electric Booster 7.1 kW; Electric Heating Unit 5.4 kW |
| Number of Wash Cycles | 4 Cycles |
| Wash Cycle Time | Adjustable based on preference - Timed wash cycles for 1, 2, 4 or 6 minutes |
| Racks Per Hour | Up to 52 Racks / hr or Up to 1300 Dishes (average 25 per rack) / hr or Up to 2340 Glasses (average 45 per rack) / hr |
| Water Usage | 0.67 Gallons Per Rack (Rinse); 34.84 Gallons per Hour (Max. Consumption) |
| Warranty | One year parts and labor warranty provided by Hobart |
| Product Type | Door-type dishwasher, High Temp, Automatic Soil Remove, Tall Chamber |
| Style | High-Temp Sanitizing |
| Electrical | 208-240v/60/3 (Field Convertible to 1Ph) |
