Fast Kitchen Hood PS-SSH-MUA-F Wall Type Make Up Air Commercial Exhaust Hood for Limited Space

Description: FAST wall-type exhaust hood model PS-SSH-MUA-F complete with baffle filters. Ideal for kitchens with limited ceiling space and avoid extensive duct work to multiple ceiling diffusers. For heavy cooking applications (woks, char broilers, live charcoal, etc.).

Construction: Exposed hood surface: type 430 stainless steel (304 optional) with #4 finish (brushed). Non-exposed hood surface: stainless steel with #2B finish. Minimum 18-gauge (1.2 mm) thickness. All visible welded joints are polished to match original finish. To meet NFPA- 96 requirements.

Installation: Suspension (recommended height) The hood should be installed 6’ 6” (1,981 mm) from the floor. Hanging brackets are welded at all four corners. Semi-combustible materials A clearance of 3” (76 mm) is required when the hood is in contact with semi-combustible materials. As per NFPA-96 standards, a stainless steel spacer will be required.

Electrical: Junction box and pre-wiring for lighting system may be factory installed if required.

Specifications:
• Constructed of sturdy 18-gauge (1.2 mm) stainless steel
• Available in lengths of 3’ 0” to 16’ 0” (914 mm to 4,877 mm)
• Washable baffle filters
• Replacement tempered air distributed at front of hood
• Improves productivity by ensuring efficiency, performance and comfort for the kitchen staff
• Easy installation
• Listed NSF, ETL and
• Many options available (see reverse)
• Quick delivery

Enclosure panels (optional): The space between the top of the hood and the ceiling may be closed with stainless steel panels in the same finish as the hood.
