Axis AX-VB3 90 lbs Gas Vertical Broiler - 3 Burner 34,140 BTU

CAD $1,999.00
  • All heavy-duty stainless steel construction
  • Three infrared burners with individual controls
  • Unique E-Z slide dual-rail system for flexible cooking
icon-0 icon-1

AX-VB3 90 lbs Gas Vertical Broiler - 3 Burner 34,140 BTU

With gyros, shawarma, and doner kebabs becoming more and more of a popular eat; your Mediterranean restaurant will need a broiler that will effectively cook your meats and can be easily sliced for serving. The AXIS heavy-duty broiler comes with all-stainless steel construction and an enclosed motor.

Standard Features

  • All heavy-duty stainless steel AISI 304 construction for hygiene
  • Unitized base provides a strong and reliable professional appliance
  • Infrared burners and can be operated individually
  • Electric motor positioned at the top of the unit away from any fats
  • Motor rotates both clockwise and counter-clockwise
  • If the flame extinguishes, the thermo-elements will cut any gas flow
  • Individual burner controls and removable drip tray are furnished
  • With our unique E-Z slide dual-rail system, the operator can broil the meats closer or further from the heat source; as well as angled
  • Available in three or four-burner configuration (AX-VB3/AX- VB4)
  • 120-volt cord and plug required for motor rotation. NEMA 5-15P
  • Broilers are shipped ready for natural gas installation. An LP conversion kit is included with each unit.
  • ETL and NSF approved

Technical Specifications

  • Model: AX-VB3
  • Spit Height: 24”
  • Power:  34,140 BTU
  • Meat Capacity: 88lb
  • Ship Weight: 62lb
  • Dimensions (WDH): 18” x 22” x 39”
  • *Gas Connection: ½” NPT (pressure regulator is required but not included)
  • *Gas Pressure: 7” – 8” W.C Natural Gas/ 10” – 13” W.C Propane

barcodeUPC: 6997390001073





Resources and Download

SPECSHEET ( 414.02 kB)
EXPLODED VIEW ( 445.47 kB)
